The main difference between ASUS ZenWiFi XD5 and ASUS ZenWiFi XD4, an updated platform based on a quad-core Broadcom BCM6756 1.7 GHz processor, has received a significant increase in performance, which was lacking in the previous line, providing greater network performance, also adding support for 160 MHz for the 5 GHz band, increasing class up to AX3000. Otherwise, the ASUS ZenWiFi XD5 model does not differ from its predecessor and comes with two antennas that are hidden inside the device’s plastic case. Despite its small size, the wireless range of each ZenWiFi XD5 node is slightly less than that of the ASUS RT-AX58U.
ASUS ZenWiFi XD5 Feature:
Support for WiFi 6 (802.11 ax) standard and 160 MHz channel width
High data rate: 2.4 GHz band – 574 Mbps and 5 GHz band – 2402 Mbps
Used MIMO scheme: in the range of 2.4 GHz and 5 GHz – 2 × 2: 2
MU-MIMO and OFDMA technologies – provide efficient work with multiple connected devices simultaneously
Target Wake Time technology – allows you to reduce power consumption by allocating time intervals during which data will be transferred. Client devices will go to sleep during periods of inactivity
Free information security system AiProtection Classic based on Trend Micro technologies
Agile Multiband Technology – improved interoperability to reduce switchover time from one access point to another access point
Compatible with ASUS AiMesh technology for extended wireless range
ASUS ZenWiFi XD5 Spec:
| Model Name | ASUS XD5 (W-3-PK) XD5 (W-1-PK) XD5 (B-1-PK) XD5 (B-3-PK) XD5 (B-2-PK) XD5 (W-2-PK) |
| Network Standard | IEEE 802.11a IEEE 802.11b IEEE 802.11g WiFi 4 (802.11n) WiFi 5 (802.11ac) WiFi 6 (802.11ax) IPv4 IPv6 |
| Product Segment | AX3000 ultimate AX performance : 2402 Mbps+ 574 Mbps |
| Data Rate | 802.11a : up to 54 Mbps 802.11b : up to 11 Mbps 802.11g : up to 54 Mbps WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps WiFi 6 (802.11ax) (5GHz) : up to 2402 Mbps |
| Antenna | Internal dual-band antenna x 2 |
| Transmit/Receive | 2.4GHz 2×2 5GHz 2×2 |
| Operating Frequency | 2.4 GHz / 5 GHz |
| Ports | RJ45 for Gigabits BaseT for WAN/LAN x 1, RJ45 for Gigabits BaseT for LAN x1 |
| Package content | ‧Router (XD5R) ‧Node (XD5N) ‧RJ45 Ethernet cable ‧Power adapter ‧Quick start guide ‧Warranty Card |
ASUS ZenWiFi XD5 Advantage:
Whole-home Coverage
The ASUS ZenWiFi XD5 system consists of three ASUS AX3000 WiFi 6 routers, featuring unique technologies that give you superfast, reliable and secure WiFi connections– inside or outside your home!
WiFi 6 True 8K Streaming
ASUS ZenWiFi XD5 puts your WiFi into top gear! With a total bandwidth of up to of 3000 Mbps, it’s up to 3X faster * than WiFi 5 routers
Explore ultimate WiFi 6 performance
The ASUS ZenWiFi XD5 supports high-speed 160MHz bandwidth. It dramatically increases network capacity while reducing congestion, delivering higher performance for every WiFi 6 device.
Flexible Network Naming
Uniquely, ZenWiFi lets you choose how you name your WiFi networks: a single name for everything, or separate names for each frequency band. The choice is yours!
Easier-than-ever Setup
What makes ASUS ZenWiFi XD5 setup so easy?
One-time setup, with auto synchronization for all the hubs in each package
Use a network cable to connect your modem to the WAN port of one ASUS ZenWiFi XD5. This ZenWiFi XD5 will be the AiMesh router, and the other two ZenWiFi XD5 will be the AiMesh nodes.
Make the Internet a Safer Place for Everyone
AiProtection Classic with Parental Controls is free for life. It gives you total peace of mind, and you can keep an eye on everything that’s happening on your network via the mobile app.
Smart Looks for Smart Homes
ASUS ZenWiFi XD5 works perfectly with smart-home services– including Alexa skills– and is available in charcoal or white to suit your décor.
AiMesh Technology
Easy setup. Flexible management.
Even non-experts can quickly set up AiMesh technology, while more experienced users will appreciate the comprehensive advanced networking features.
Verdict
Overall, the ASUS ZenWiFi XD5 is a great product for anyone looking for a mesh WiFi system. It has good Wi-Fi coverage despite its small size. This model does not have all the features of the more expensive ZenWiFi XT8 or ZenWiFi XT9, it should be enough for most users.
